| 00047104-01 | 00047104 | 47104 | Plug B-M5-AI |
| 00047555S01 | 00047555 | 47555 | Plastic Hose, PU-4, blue, 5m each |
| 00048315-01 | 00048315 | 48315 | GRIPPING RING |
| 00048346-01 | 00048346 | 48346 | DIN 6799 - 8-ST |
| 00066141-01 | 00066141 | 66141 | Feeder Bags 650mm |
| 00066172-02 | 00066172 | 66172 | PROTECTION COVER FOR INTERMEDIATE PCB |
| 00066173-03 | 00066173 | 66173 | PACKAGE INSIDE FOR HEAD 6/12 |
| 00066191S01 | 00066191 | 66191 | PACKAGE FOR FEEDER 12/16 S |
| 00066192S01 | 00066192 | 66192 | PACKAGE FOR FEEDER 24/32 S |
| 00066193S01 | 00066193 | 66193 | PACKAGE FOR FEEDER 44 S |
| 00066268-01 | 00066268 | 66268 | Pack for 3x8mmS-Feeder |
| 00066298-01 | 00066298 | 66298 | PACKAGE FOR FEEDER 88 mm S |
| 00066312S01 | 00066312 | 66312 | PLASTIC CASE 375*270*90 ESD |
| 00066315-01 | 00066315 | 66315 | PE-FOAM INSERT FOR BOX 00325829-01 |
| 00091001-02 | 00091001 | 91001 | Gloves Leather |
| 00092020-01 | 00092020 | 92020 | JOBBER TWIST DRILL 1,1 |
| 00092022-01 | 00092022 | 92022 | JOBBER TWIST DRILL |
| 00092026-01 | 00092026 | 92026 | JOBBER TWIST DRILL |
| 00094020-01 | 00094020 | 94020 | THICKNESS GAUGE 0,05 - 1,00mm |
| 00095304-01 | 00095304 | 95304 | Countersunk screw DIN965-M3x6-4.8 |
| 00095312S01 | 00095312 | 95312 | SCREW M4*10 DIN965 |
| 00095474-01 | 00095474 | 95474 | Disc 6,4 DIN125-A |
| 00095482-01 | 00095482 | 95482 | DIN 471-6x0.7-C67 |
| 00095614-01 | 00095614 | 95614 | DIN 6325-3m5x18-St |
| 00096201-01 | 00096201 | 96201 | ALLAN KEY 0,9 mm |
| 00096203-01 | 00096203 | 96203 | ALLAN KEY 1,3 mm |
| 00096217-01 | 00096217 | 96217 | ALLEN/Hex KEV SET |
| 00096290-01 | 00096290 | 96290 | SPANNER SET 15 PIECES |
| 00098614-01 | 00098614 | 98614 | DEEP-GROVE BALL BEARING 4*13*5 624-2Z |
| 00098614S01 | 00098614 | 98614 | DEEP-GROVE BALL BEARING 4*13*5 624-2Z |
| 00098615-01 | 00098615 | 98615 | DEEP-GROOVE BALL BEARING 5*16*5 625 2Z |
| 00098616S01 | 00098616 | 98616 | DEEP-GROOVE BALL BEARING 19*6*6 626-2Z |
| 00098617S01 | 00098617 | 98617 | BALL BEARING |
| 00098618S01 | 00098618 | 98618 | BALL BEARING 8*22*7 608 2Z |
| 00116076-03 | 00116076 | 116076 | TRANSPORTHIGHT 930/950 CHANGE-OVER-TABLE |
| 00116088-02 | 00116088 | 116088 | Transport height 900mm, for change-over table. Adapting of SIPLACE change-over tables on transport height 900mm. |
| 00116113S01 | 00116113 | 116113 | Set placement head nozzle sleeves for SIPLACE 80S-20/F4/F5/S23HM/HS50 12 units, with air blow. Additional set for change over in case of cleaning purpose to raise station time. |
| 00116114S01 | 00116114 | 116114 | Set Nozzle Sleeves (6) SIPLACE |
| 00116140-02 | 00116140 | 116140 | Regulator unit for linear and bulk vibrator feeders for use with 142025 Type II. Required for use with SIPLACE . 1 regulator unit required per module. |
| 00116161-03 | 00116161 | 116161 | Nozzle changer for 12-Segment Collect and Place Head SIPLACE F5 HM.Station software version 402.xxx and later. Line software version 402.xxx and later. Option includes: 7 magazines, each for 12 nozzles. |
| 00116162S02 | 00116162 | 116162 | Nozzle changer for 6 nozzle C+P Head SIPLACE 80 F4/F5 Station software version 403.xxx or higher Line computer software 403.xxx or higher Option includes: 2 magazines for big nozzles 3 magazines for small nozzles |
| 00116190-01 | 00116190 | 116190 | Upgrade kit to use outdated feeder changeover tables on SIPLACE S-20, F4, F5 HM together with moveable feeder changeover tables. |
| 00116220-01 | 00116220 | 116220 | Adapter plate SIPLACE S/F change-over table without wheels version 2 for reel holder 3x8mm or 3x8mm 0201/0402 feeder respectively |
| 00116225-01 | 00116225 | 116225 | An additional mechanical device to avoid incorrect feeder stand on changeover table due to improper operator handling. The mechanical attachment is required per changeover table. The additional feeder fastening attachment accommodates all SIPLACE feeders delivered since CW 34/98. Please pay attention to the preconditions which are discribed in the Product Status Report for all feeders delivered before CW 34/98. |
| 00116380-01 | 00116380 | 116380 | Kit to splice component tapes. Includes SIPLACE splicing gripper (classic version for single strips), splice strip box, tape connectors, tape threaders, holder, operater tools, Job Poster. For first equipping of new customers. |
| 00116416S01 | 00116416 | 116416 | Additional component vision module SIPLACE 80 F/F4/F5 for flip chip bump centering. Field of view: 9mmx11.5mm. Largest flip chip with single measurement: 7mm x 9mm.Smallest,reliably recognizable bump diameter: 0,1mm. Reliable processing of IC pitch: 0,25mm |
| 00116417S01 | 00116417 | 116417 | Additional component vision module SIPLACE 80 F/F4/F5 for flip chip bump centering. Field of view: 9mmx11.5mm. Largest flip chip with single measurement: 7mm x 9mm.Smallest,reliably recognizable bump diameter: 0,1mm. Reliable processing of IC pitch: 0,25mm |
| 00116421S03 | 00116421 | 116421 | Additional nozzle changer for IC head |
| 00116430-01 | 00116430 | 116430 | Waffle-Pack-Magazine mounting for SIPLACE. Mounted succeeds on the component changeover table. 9 feeder locations required. Required for use with item no. 116431. |
| 00116807-01 | 00116807 | 116807 | SMEMA Interface for single and dual conveyor SIPLACE S/F. |
