Surface Mount Technology (SMT) involves mounting electronic components directly onto the surface of PCBs[3]. An SMT line is a series of interconnected machines that automate this process, offering higher component density, improved reliability, and reduced manufacturing costs compared to older through-hole technology [3, 5].
The SMT assembly process with a Samsung/Hanwha SMT line typically involves the following steps [1, 2, 3]:
A solder paste printer applies solder paste to the PCB pads where components will be placed. Precision in this step is crucial.
A pick and place machine, often a Samsung or Hanwha model, accurately places surface mount components onto the PCB. Samsung/Hanwha pick and place machines are known for their accuracy and speed [5, 8]. These machines pick up surface-mount devices from reels or trays and place them accurately onto the PCB using a combination of vacuum and mechanical grippers. The orientation, location, and pad size for the SMT components will be programmed onto the machine from the picking place files.
The board is heated in a reflow oven, melting the solder paste and creating permanent solder joints. Serviampt offers SRF Lead Free Reflow Ovens[7].
Automated Optical Inspection (AOI) is used to check for defects such as missing components or misalignment [1, 2, 3].
Once the PCB has passed all inspections and tests, it moves to the final assembly stage. This may include additional steps like attaching heat sinks, housings, or connectors.
A typical Samsung/Hanwha SMT line consists of several interconnected machines, each performing a specific function:
* Solder Paste Printer: Applies solder paste to the PCB with high precision[5].
* Samsung/Hanwha Pick and Place Machine: Accurately places surface mount components onto the PCB [5, 8]. The SMT pick and place machine, also known as chip mounter, plays a crucial role in the SMT production line[5]. Hanwha SMT machine models include the SM471 Plus and SM481 Plus [5, 7].
* Reflow Oven: Melts the solder paste to form solder joints[7].
* Automated Optical Inspection (AOI) Machine: Inspects the PCB for defects [2, 3].
* High Speed and Efficiency: Samsung/Hanwha SMT lines are designed for high-speed and efficient PCB assembly [3, 5, 7]. Hanwha's HM520 SMT series are high-speed chip mounters[3].
* High Accuracy: Samsung/Hanwha pick and place machines are known for their high accuracy [5, 8]. The DECAN S2 offers accuracy of ±28μm Cpk≥1.0 (03015 Chip) and ±25μm Cpk≥1.0 (IC)[7].
* Component Flexibility: Samsung/Hanwha SMT lines can handle a wide range of components, from small chips to large connectors. The SM481 Plus can handle parts from 0402 (01005")~□42mm(H15mm)[7].
* Improved Quality Control: Automated inspection systems help ensure high-quality PCBs [2, 3].
* Smart Factory Solutions: Hanwha offers integrated software solutions such as T-Solution to meet the demand for smart, automated machinery[3].
Before investing in a Samsung/Hanwha SMT line, consider the following factors:
* Production Needs: Analyze your production volume, component complexity, and changeover frequency.
* Budget: Determine your budget, including initial investment and ongoing maintenance costs.
* Equipment Capabilities: Assess whether the machines can handle your component range and PCB sizes [5, 7]. The DECAN S2 can handle PCB sizes L510xW460mm (Standard) or L1,200xW460mm (Option)[7].
* Integration: Evaluate how well the equipment integrates with your existing systems.
* Support and Training: Ensure the availability of adequate support and training.
* SMEMA Compatibility: Ensure all equipment is SMEMA compatible.
* Smart Factory Integration: How well the SMT line integrates with your existing systems[3].
While Samsung no longer manufactures SMT lines, Hanwha Precision Machinery continues to produce and support them [6, 7]. You may need to work with a distributor or partner for integration and support. When choosing a Samsung/Hanwha SMT line manufacturer or supplier, consider:
* Experience: Choose a company with a proven track record working with Samsung/Hanwha equipment[6]. allSMT has been supplying used machines from Hanwha & Samsung since 2003[6].
* Expertise: Ensure they have the technical expertise to support your specific needs.
* Service and Support: Confirm they offer comprehensive service and support [1, 7].
* Customer Reviews: Check their reputation and customer reviews.
allSMT and I.C.T SMT Machine are options to consider [2, 5, 6]. ETA is a supplier for Hanwha SMT Chip Shooters[9]. PT SERVIAM ABADIMURNI is another supplier [2, 7].
The cost of a Samsung/Hanwha SMT line varies depending on the configuration and capabilities of the equipment. Conduct a thorough cost analysis, including:
1. Initial Investment: The purchase price of the machines.
2. Installation Costs: Expenses related to setting up the equipment.
3. Training Costs: The cost of training personnel.
4. Operating Costs: Ongoing expenses, such as labor and materials.
5. Maintenance Costs: Costs for regular maintenance and repairs.
Compare these costs with the potential benefits, such as increased production, reduced labor, and improved quality.
A Samsung/Hanwha SMT line offers a reliable and efficient solution for PCB assembly. However, deciding whether it is the best choice requires careful consideration of your specific needs, budget, and production goals. Evaluating Samsung/Hanwha's offerings, considering the factors outlined above, and comparing with alternatives will help you make an informed decision.
A: To automate the process of assembling electronic components onto the surface of PCBs [3, 5].
A: Solder paste printer, Samsung/Hanwha pick and place machine, reflow oven, and AOI machine [5, 7].
A: High speed, high accuracy, component flexibility, improved quality control, and smart factory integration [3, 5, 7, 8].
A: Production needs, budget, equipment capabilities, integration, support, and training.
A: Hanwha Precision Machinery [6, 7].
